Detailinformationen |
|||
| Modell Nr.: | VS-052 ~ VS-400 | Arbeitstyp: | Rotation |
|---|---|---|---|
| Druck: | Mittlerer Druck | Arbeitstemperatur: | Normale Temperatur |
| Material: | Aluminium | Zahntriebmaterial: | Verhärteter legierter Stahl |
| Ritzelbeschichtung: | Vernickelt (über 15 µm) | Beschichtung des Aktuatorkörpers: | Hart eloxiert (über 30 µm) |
| Endkappenbeschichtung: | Epoxidbeschichtet (über 80 µm) | Kolbenbeschichtung: | Hart eloxiert (über 30 µm) |
| Reiseanpassung: | ±5º | Federmaterial: | Hochfester Stahl |
| Federbeschichtung: | Epoxy-Kleber beschichtet | Lagermaterial: | Äußerst haltbare Verbindung |
| Produktionskapazität: | 50000pc / y | ||
| Hervorheben: | Travel Adjustment ±5º Pneumatic Actuator,Position Indicator Pneumatic Air Actuator,High Performance Springs Rotary Actuator |
||
Produkt-Beschreibung
Pneumatic Actuator Cylinder Pneumatic Valve Control
Product Features
- Indicator: Position indicator with Namur mounting for accessory attachment
- Pinion: Hardened alloy steel pinion, precision ground and nickel plated (over 15μm) for reduced friction and maximum wear resistance. Complies with ISO5211 & DIN3337 standards. Custom dimensions available with stainless steel and aluminum alloy options.
- Actuator Body: Hard anodized aluminum extrusion (over 30μm) for wear and corrosion protection with minimal piston friction. Optional Epoxy Coated and PTFE Coated treatments available.
- End Cap: Epoxy coated (over 80μm) die casting aluminum for maximum corrosion resistance. PTFE Coated options available.
- Piston: Precisely balanced, hard anodized (over 30μm) die casting aluminum with high-quality guides. Twin rack and pinion design ensures constant torque output.
- Travel Adjustment: Standard ±5° adjustment in both open and closed positions via easily accessible external bolts.
- High Performance Springs: Epoxy coated high tensile steel for corrosion resistance and extended service life. Pre-loaded springs allow safe, rapid disassembly.
- Bearings & Guides: Highly durable compound material provides stable thrust with minimal friction and long service life.
